The rapid evolution of generative AI and large language models (LLMs) has created unprecedented demand for high-performance computing infrastructure capable of handling trillion-parameter workloads. Dell Technologies, in collaboration with NVIDIA, has emerged as a leader in delivering on-premises AI solutions that combine cutting-edge hardware, optimized software ecosystems, and enterprise-grade security. This report analyzes Dell’s portfolio of NVIDIA H100-powered servers, their architectural innovations, performance benchmarks, and transformative impact on private AI deployments across industries. By combining Dell’s PowerEdge server engineering with NVIDIA’s Hopper architecture GPUs, enterprises can now deploy air‐cooled and liquid‐cooled AI factories that rival cloud hyperscalers in performance while maintaining full data sovereignty.

The cornerstone of Dell’s on‐premises AI strategy is Project Helix, a full‐stack solution developed with NVIDIA to simplify generative AI deployment. Announced in May 2023, this initiative provides enterprises with pre‐validated configurations combining Dell PowerEdge servers, NVIDIA H100 GPUs, and optimized AI software stacks. Unlike cloud‐based AI services, Project Helix enables organizations to:

• Fine-tune foundation models using proprietary data without IP leakage risks
• Achieve 30x faster inference performance on LLMs compared to previous GPU generations
• Deploy air‐cooled systems supporting up to 8x H100 GPUs in standard data center environments

The architecture leverages Dell’s PowerEdge XE9680 servers with NVIDIA’s HGX H100/H200 GPUs interconnected via NVLink, delivering 900 GB/s GPU-to-GPU bandwidth. This configuration supports trillion-parameter models while maintaining <35°C operating temperatures through advanced airflow designs.

Dell’s Validated Design for Generative AI reduces implementation timelines from months to weeks through pre-tested hardware/software stacks:

• Hardware Foundation: PowerEdge XE8640 (4x H100 SXM5) and XE9680 (8x H100 PCIe) configurations
• Software Stack: NVIDIA AI Enterprise 4.0 with NeMo framework and Triton Inference Server
• Storage Integration: PowerScale all‐flash arrays with GPUDirect RDMA achieving 2.5TB/s throughput
• Security: Silicon Root of Trust and cryptographic supply chain verification

These designs have demonstrated 67% higher HPC performance per watt compared to previous A100‐based systems, making them viable for exascale computing workloads.

Flagship Models and Configurations

PowerEdge XE9680: The AI Workhorse

• 8x NVIDIA H100 PCIe Gen5 GPUs (700W TDP each)
• Dual 4th/5th Gen Intel Xeon CPUs (64 cores)
• 16x DDR5-4800 DIMM slots (2TB RAM)
• 8x PCIe Gen5 x16 slots for NVMe storage

In MLPerf Training v4.0 benchmarks, a 4x H100 configuration achieved:

• 3.2 exaflops FP8 performance on BERT-Large
• 89% scaling efficiency across 256 GPUs in ResNet-50

The server’s modular design allows hybrid cooling – air‐cooled for standard deployments or direct‐liquid cooling for density‐optimized racks.

PowerEdge XE8640: Balanced Performance

Targeting mid-range AI workloads:

• 4x H100 SXM5 GPUs with NVLink interconnects
• 2x Intel Xeon CPUs (32 cores)
• 12x NVMe Gen5 drives (183TB raw storage)
• NVIDIA BlueField-3 DPUs for network offloading

This 4U system demonstrates 1.5x higher bandwidth than previous SXM4 designs, critical for LLM training.

Memory Architecture

The H100’s 141GB HBM3e memory (vs. A100’s 40GB) enables:

• Training 175B-parameter models without pipeline parallelism
• 4.8TB/s memory bandwidth for attention mechanisms in transformers
• NVIDIA MIG technology partitioning GPUs into 7x 20GB instances

When combined with Dell’s GPUDirect Storage, data staging latency is reduced by 72% compared to CPU-managed transfers.

Energy Efficiency

Through Smart Flow design and Power Manager software:

• 35% lower PUE in air-cooled deployments vs. industry average
• Dynamic GPU clock scaling saving 200W per node during inference
• 94% PSU efficiency at 50% load

Storage and Data Pipeline Optimization

Dell’s PowerScale F900 all‐flash arrays address AI’s voracious data needs:

• RDMA over Converged Ethernet (RoCEv2) reduces CPU overhead by 40%
• OneFS 9.7 supports 186PB single namespace for distributed training datasets
• NVIDIA MagnumIO accelerates >1 million IOPS for Parquet/ORC files

A typical ResNet-50 training workflow sees 2.1x faster epoch times when using PowerScale’s data prefetching algorithms.

Security Architecture

Project Helix integrates multiple security layers:

• Hardware Root of Trust: TPM 2.0 + Secure Boot for firmware validation
• Data Encryption: AES-256 for data-at-rest and in-flight between GPUs
• NVIDIA Morpheus: AI-driven anomaly detection blocking 98% of zero-day attacks
• Dell’s Cyber Recovery Vault provides air-gapped protection for model checkpoints and training data

Total Cost of Ownership (TCO) Comparison for a 3-Year AI Cluster:

Source: Dell TCO Calculator

The 37.5% cost savings stem from:

• Eliminating cloud egress fees
• Higher GPU utilization (78% vs. 53%)
• Power efficiency gains from liquid cooling

NVIDIA AI Enterprise Integration

Dell’s factory-installed software stack includes:

• NeMo Framework: Customizes Megatron-530B with proprietary data
• Triton Inference Server: 150ms latency for 175B-parameter models
• RAPIDS: GPU-accelerated data preprocessing at 45TB/hour
• The AI Workflow Builder tool automates MLOps pipelines, reducing setup time from 3 weeks to 4 hours

Meta Llama 2 Deployment Package

Through Dell’s partnership with Meta, the solution offers:

• Pre-configured Llama 2-70B containers for PowerEdge
• Fine-tuning templates for healthcare and legal domains
• Monitoring dashboards tracking GPU memory and utilization
• Early adopters report 22% higher accuracy in domain-specific tasks compared to GPT-4 API

Professional Services

Dell’s AI Implementation Services cover:

• Data Readiness Assessment: Profiling 200+ data sources for AI suitability
• Model Optimization: Quantizing FP32 models to FP8 with <1% accuracy loss
• Workload Placement: Hybrid scheduling across edge, core, and cloud GPUs
• A case study in financial services demonstrated an 8x ROI through fraud detection models running on XE8640 clusters

NVIDIA Blackwell and ARM Adoption

Upcoming PowerEdge models will support:

• GB200 NVL72: 72 Blackwell GPUs per rack with 30kW liquid cooling
• NVIDIA Grace CPUs: ARM-based processors for 5x better performance per watt
• Xe9680 v4: 8x H200 GPUs with 141GB HBM3e memory

These advancements aim to enable exascale AI factories within single data center racks by 2026.

Edge AI Expansion

Dell’s PowerEdge XR8000 series brings H100 capabilities to edge locations:

• Ruggedized 2U form factor designed for extreme temperatures (-40°C to 65°C)
• 4x H100 PCIe GPUs with 25Gbps TSN networking
• Preloaded edge AI models for predictive maintenance

An automotive manufacturer reduced assembly line defects by 18% using XR8000-powered vision AI.

Dell PowerEdge servers equipped with NVIDIA H100 GPUs represent the pinnacle of on-premises AI infrastructure, combining unmatched computational density with enterprise-grade manageability. Through strategic collaborations like Project Helix and continuous architectural innovation, Dell has created an AI-ready platform that:

• Delivers 30x faster inference than cloud alternatives
• Reduces model training costs by 37% over 3 years
• Supports trillion-parameter LLMs with full data governance

As enterprises increasingly prioritize data sovereignty and workload control, Dell’s H100-powered solutions provide the performance bedrock for the next generation of private AI deployments. With upcoming Blackwell GPU integration and ARM-based server designs, Dell is poised to maintain leadership in the accelerating transition to on-premises AI infrastructure.
